Enerpac RT-Series Multi-Stage Telescopic Cylinders

$0.00

GST excluded

Enerpac RT-Series Multi-Stage Telescopic Cylinders Nitrocarburized surface treatment inside and out provides corrosion protection Double or triple wear bearings support lifting stages Tiltin...

Australia Wide ShippingFast & reliable delivery

Quality AssuredPremium products

Technical SupportWe're here to help

Enerpac RT-Series Multi-Stage Telescopic Cylinders

Nitrocarburized surface treatment inside and out provides corrosion protection
Double or triple wear bearings support lifting stages
Tilting saddles with 5 degrees of maximum tilt standard on all models
Design Safety factor complies with ASME B30.1 & EN1494
Certified lifting eyes for safe handling and positioning
CR400 coupler for compatibility with standard product

Applications

Tipping and dumping mechanisms in agricultural and transport equipment
Lifting operations requiring long stroke from a compact retracted height
Vehicle recovery and underbody lifting in restricted vertical clearances
Bridge and infrastructure inspection and maintenance platform raising
Stage and theatre rigging for variable-height positioning

Download the Enerpac Hydraulic Cylinders Catalogue (PDF) – full specifications and dimensional drawings for this product range.

AD Automation is an authorised Enerpac distributor and service centre. Contact us for pricing and availability.

Model Number	Capacity (ton/kN)	Max Stroke (mm)	Coll. Height A (mm)	Ext. Height B (mm)
RT1510	14,0 (137)	270	283	553 780 617 895 652 1076
RT1817	17,0 (166)	435	345	780
RT2111	20,2 (198)	300	317	780
RT2119	20,2 (198)	500	395	895
RT3311	31,5 (309)	300	352	895
RT3323	31,5 (309)	600	476	1076

Suitable for lifting, pressing, pushing, pulling and clamping in industrial applications including mining, rail, construction, manufacturing and maintenance environments.
