Enerpac RLT-Series Low-Height Telescopic Cylinders

Single-acting, load-return
Nitrocarburized surface treatment inside and out provides corrosion protection
For use in confined spaces: machinery positioning, tool fastening
Mounting bolt holes for easy fixing
Up to 3% side load of maximum capacity
Design safety factor complies with ASME B30.1 & EN1494
CR400 coupler for compatibility with standard product

Applications

Extended-stroke lifting from very low retracted heights in confined access conditions
Vehicle and equipment underbody lifting in restricted inspection pits
Bridge and infrastructure maintenance with minimal headroom clearance
Agricultural equipment and trailer tipping mechanisms
Stage and theatre rigging requiring a compact retracted height with long travel

Download the Enerpac Hydraulic Cylinders Catalogue (PDF) – full specifications and dimensional drawings for this product range.

AD Automation is an authorised Enerpac distributor and service centre. Contact us for pricing and availability.

Model Number	Capacity (ton/kN)	Max Stroke (mm)	Coll. Height A (mm)	Ext. Height B (mm)
RLT40	4,4 (43)	17	45,0	62,0
RLT41	4,4 (43)	23	54,0	77,0
RLT110	11,4 (111)	18	54,5	72,5
RLT111	11,4 (111)	40	89,0	129,0
RLT230	23,7 (232)	27	75,0	102,0
RLT231	23,7 (232)	32	96,0	128,0
RLT311	31,5 (309)	29	89,0	118,0
RLT501	50,6 (496)	26	96,0	122,0
RLT741	74,1 (727)	26	114,0	140,0

Suitable for lifting, pressing, pushing, pulling and clamping in industrial applications including mining, rail, construction, manufacturing and maintenance environments.
