Enerpac RACH-Series Aluminum Hollow Plunger Cylinders

Hollow plunger design allows for both pull and push forces
Composite bearings increase cylinder life and side load resistance
Hard-Coat finish on all surfaces resists damage and extends cylinder life
Floating center tube increases seal and product life
Handles standard on all models
Steel base plate and saddle for protection against load-induced damage
Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
High-strength return spring for rapid cylinder retraction

Applications

Lightweight bolt and tie-rod tensioning in corrosion-sensitive environments
Marine and offshore maintenance requiring hollow-plunger over-bolt access
Pre-stressed concrete operations requiring lightweight through-hole tensioning
Post-tensioning strand and bar pull in structural repair and upgrade applications
Laboratory testing and calibration with through-hole load application

Download the Enerpac Hydraulic Cylinders Catalogue (PDF) – full specifications and dimensional drawings for this product range.

AD Automation is an authorised Enerpac distributor and service centre. Contact us for pricing and availability.

Model Number	Capacity (ton)	Capacity (kN)	Stroke (mm)	Eff. Area (cm²)	Oil Cap. (cm³)	Coll. Height A (mm)	Ext. Height B (mm)	OD (mm)	Weight (kg)
RACH202	20	229	50	32,7	164	188	238	100	5,2
RACH204	20	229	100	32,7	327	251	351	100	6,1
RACH206	20	229	150	32,7		315	465	100	7,1
RACH208	20	229	200	32,7	654	378	578	100	8,0
RACH2010	20	229	250	32,7		442	692	100	9,0
RACH302	30	358	50	51,1	256	208	258	130	8,0
RACH304	30	358	100	51,1		267	367	130	9,5
RACH306	30	358	150	51,1	766	333	483	130	11,2
RACH308	30	358	200	51,1		395	595	130	12,9
RACH3010	30	358	250	51,1	1277	458	708	130	14,5
RACH602	60	596	50	84,7	423	251	301	180	16,2
RACH604	60	596	100	84,7	847	315	415	180	19,5
RACH606	60	596	150	84,7		380	530	180	25,6
RACH608	60	596	200	84,7	1694	445	645	180	26,0
RACH6010	60	596	250	84,7		510	760	180	29,6
RACH1002	100	1157	50	164,6	823	258	308	250	33,8
RACH1004	100	1157	100	164,6		325	425	250	39,8
RACH1006	100	1157	150	164,6	2487	391	541	250	46,2
RACH1008	100	1157	200	164,6		459	659	250	52,2
RACH10010	100	1157	250	164,6	4114	527	777	250	58,8
RACH1502	150	1588	50	225,8	1129	280	330	275	48,9
RACH1504	150	1588	100	225,8	2258	360	460	275	55,7
RACH1506	150	1588	150	225,8		430	580	275	63,0
RACH1508	150	1588	200	225,8	4517	500	700	275	70,1
RACH15010	150	1588	250	225,8		570	820	275	77,2

Suitable for lifting, pressing, pushing, pulling and clamping in industrial applications including mining, rail, construction, manufacturing and maintenance environments.
