Enerpac Hydraulic Nuts

Highly Accurate & Repeatable Bolt Loads
Ideal where space limitations prevent use of standard detachable tensioners
Direct Axial Loading - No nut rotation required
Multiple Nuts can be connected and tightened / loosened simultaneously
Eliminates issues with Friction
Substantial time savings due to the quick set-up and hydraulic nuts remaining in-situ
No stud or flange damage (Galling, Seizure)
No need to change joint hardware â€“ system works with existing studs

Applications

Precision pre-loading of threaded fasteners on rotating machinery shafts
Wind turbine main shaft and main bearing housing assembly
Marine propeller shaft, stern tube and stern seal assembly
Rolling mill roll change and heavy machinery bearing assembly
High-integrity bolted connections requiring verified, repeatable bolt load

Download the Enerpac Bolting Tools Catalogue (PDF) – full specifications and dimensional drawings for this product range.

AD Automation is an authorised Enerpac distributor and service centre. Contact us for pricing and availability.

Model Number	Thread Size	Max Load (kN)	Working Pressure (bar)	OD (mm)	Height (mm)	Weight (kg)
HN24	M24	280	1,500	50	28	0.4
HN30	M30	440	1,500	63	32	0.8
HN36	M36	630	1,500	76	36	1.2
HN42	M42	855	1,500	90	40	1.9
HN48	M48	1,115	1,500	105	45	2.7
HN56	M56	1,515	1,500	120	52	4.2
HN64	M64	1,975	1,500	138	58	5.8
HN72	M72	2,500	1,500	156	65	8.0
HN80	M80	3,080	1,500	174	72	11.5
HN90	M90	3,905	1,500	196	80	16.0
HN100	M100	4,800	1,500	218	88	22.5

Suitable for lifting, pressing, pushing, pulling and clamping in industrial applications including mining, rail, construction, manufacturing and maintenance environments.
