Enerpac FTE-Series Foundation Bolt Tensioners (Elliptical)

FTE-Series Foundation Bolt Tensioners provide fast and accurate performance in difficult, narrow access foundation tensioning applications
Standard models are available for 75, 150 ksi and metric style Williams, Dyson and MacalloyÂ® bar types

Applications

Tensioning anchor bolts in tight bolt-circle patterns where round profiles do not fit
Wind turbine tower base tensioning with closely spaced, dense bolt groups
Large civil structures, bridges and viaducts with restricted anchor bolt pitch
Industrial machinery base plate tensioning on small-diameter or dense bolt-circle flanges
Offshore jacket and foundation bolt tensioning where access between bolts is constrained

Download the Enerpac Bolting Tools Catalogue (PDF) – full specifications and dimensional drawings for this product range.

AD Automation is an authorised Enerpac distributor and service centre. Contact us for pricing and availability.

Model Number	Thread Size	Tensioning Force (kN)	Working Pressure (bar)	Height (mm)	Weight (kg)
FTE-M24	M24	264	1,500	80	1.2
FTE-M30	M30	412	1,500	95	1.8
FTE-M36	M36	594	1,500	110	2.8
FTE-M42	M42	808	1,500	128	4.0
FTE-M48	M48	1,057	1,500	145	5.4
FTE-M56	M56	1,437	1,500	168	8.5
FTE-M64	M64	1,878	1,500	190	11.5

Suitable for lifting, pressing, pushing, pulling and clamping in industrial applications including mining, rail, construction, manufacturing and maintenance environments.
