Enerpac PARG1102N

Images are for illustration purposes only. Actual product may vary.

Enerpac PARG1102N

$3,059.60

GST excluded

The Enerpac PARG1102N is a Turbo II compact air-over-hydraulic pump, rated to 700 bar maximum operating pressure. Featuring a high-efficiency cast aluminium air motor, the Turbo II delivers reliabl...

Custom Quote →

🔒 Secure checkout. Trusted payment processing.

Australia Wide ShippingFast & reliable delivery
Quality AssuredPremium products
Technical SupportWe're here to help

The Enerpac PARG1102N is a Turbo II compact air-over-hydraulic pump, rated to 700 bar maximum operating pressure. Featuring a high-efficiency cast aluminium air motor, the Turbo II delivers reliable hydraulic power with low air consumption for use in demanding industrial environments.

Key Features

  • High-efficiency cast aluminium air motor for increased life and reduced air consumption
  • Fully serviceable air motor assembly
  • Reinforced heavy-duty reservoir for applications in tough environments
  • Air-saver piston with rugged one-piece design reduces air consumption and operating costs
  • Return-to-tank port for use in remote valve applications
  • Quiet — only 76 dBA with low air consumption of 340 l/min
  • Operating air pressure: 2.8 – 8.8 bar — enables pump to start at extremely low pressure
  • Internal pressure-relief valve provides overload protection
  • Mounting Bracket Kit (MTB1) available to mount pumps to horizontal or vertical surfaces

Specifications

Model PARG1102N
Maximum Operating Pressure 700 bar
Usable Oil Capacity 2081 cm³ (2.08 litres)
Air Pressure Range 2.8 – 8.8 bar
Air Consumption 340 l/min
Sound Level 76 dBA
Valve Function Advance / Retract
Cylinder Operation Single-acting

Specifications sourced from Enerpac Industrial Tools Catalog E331a EN-AU.

Watch: PATG-Series Turbo 2 Air Hydraulic Pump | Enerpac

Enerpac E331a Catalogue — Hydraulic Pumps

Full specifications, performance data and selection guide for the complete Enerpac pump range.

Download PDF
SpecificationValue
ModelPARG1102N
DriveAir Turbine (PA Turbo II)
TypeAir Turbo II, Return-Spring, 2-stage
Max Pressure700 bar (10,000 psi)

Suitable for lifting, pressing, pushing, pulling and clamping in industrial applications including mining, rail, construction, manufacturing and maintenance environments.

Australia-wide delivery available. Contact our team for lead times on specific configurations. Technical support available Mon – Fri: 9:00am – 4:00pm.

Contact our team for stock availability and express options.
